MEGA 410 Watt Monocrystalline Solar Panel | High Efficiency | Black Mono-facial Module | Grid-Tie | Off-Grid
Been looking for the off-grid solar system for you? This MEGA 410 Watt Solar Panel is one of the most best solar panels for grid-tie and off-grid system. Get this to start your solar adventure today!
Features
- 10 buss bar solar cell configuration
- Mono PERC Technology
- Lightweight anodized aluminum frame
- High Transmission, AR (anti-reflective) Coated Tempered Glass
- Plug and play junction box
- Industry standard quick connect cables work in series or in parallel
- Certified to withstand challenging environmental conditions
- Excellent low light performance on cloudy days, mornings and evenings
Installation
- Easy installation and handling for various applications (high-end off-grid and mobile applications)
- Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts and tilt mounts
- Compatible with on-grid and off-grid inverters
Warranty
- 25 year limited power output
Specs
SPECIFICATIONS
| ATTRIBUTE | VALUE |
| Maximum Power(Pmax) | 410W |
| Maximum Power Voltage(Vmp | 31.3V |
| Maximum Power Current(Imp) | 13.1A |
| Open Circuit Voltage(Voc) |
37.5V
|
| Short Circuit Current(Isc) | 13.8A |
| Maximum System Voltage(Vmax) | 1500VDC |
| Temperature Range | -40°F ~ 185°F |
| Max Series Fuse Rating | 25A |
| Weight | 45.2 lb |
| Dimensions | 67.9 x 44.6 x 1.2 in |
