Ranger DST30P Wheel Balancer + R980XR Tire Changer + Tape Wheel Weights Combo

This complete setup brings together precision, speed, and reliability for a professional-grade tire service station. Featuring the Ranger R980XR Tire Changer and DST30P Wheel Balancer, this combo ensures smooth, efficient operation from start to finish. Paired with a full roll of adhesive tape weights, it’s everything your shop needs for quick, accurate results in one streamlined package — perfect for garages that demand performance without wasting floor space.

Included in This Package

DST30P Wheel Balancer (5140154) — Qty: 1

• Type: Wheel Balancer / 36 mm Shaft / Six-Second Balancing
• Designed to save time and reduce rework, the Ranger DST30P delivers a fast and flawless balance every time. With six-second floor-to-floor operation, it calculates precise weight adjustments automatically, ensuring consistent accuracy and eliminating the hassle of manual fine-tuning.

R980XR Tire Changer (5140146) — Qty: 1

• Type: Swing Arm / 30" Capacity
• Compact yet powerful, the Ranger R980XR is built for versatility in busy workshops. It’s a great option for general tire service on performance, passenger, and light truck tires — offering the same space-efficient design as the R980AT, but without the assist tower. Ideal for everyday jobs where speed and simplicity matter most.

Tape Wheel Weights Combo (5150230) — Qty: 1

• Type: Adhesive Steel Wheel Weights / Roll (1,400 pcs, 0.25 oz each, ½" wide, 22 lbs total)
• This Quick-Peel adhesive steel weight roll provides a clean and eco-friendly way to balance wheels precisely. Each strip peels easily and sticks firmly, ensuring smooth operation with minimal added mass — the perfect finishing touch to every tire job.

Specifications

Ranger DST30P Wheel Balancer

• Shipping Weight: 398 lbs (181 kg)
• Maximum Tire Diameter: 50" (1,270 mm)
• Maximum Tire Weight: 150 lbs (68 kg)
• Wheel Diameter Range: 8" – 30" (254 mm – 762 mm)
• Wheel Width Range: 1.2" – 20" (30 mm – 508 mm)
• Motor: 1.5 HP, 110/220V, 50/60 Hz, 1Ph
• Cycle Time: 6–9 seconds (average)
• Operating Temperature: -5°C (27°F) to 50°C (82°F)
• Balancing Increments: 0.25 oz (7 g)
• Balancing Speed: 180 RPM
• Accuracy: ±1 gram (0.035 oz)
• Data Entry: Manual
• Drive System: Belt Drive
• Wheel Braking: Automatic / Electronic
• Balancing Modes: Dynamic / Static / 3-Alloy
• Cones Included: 3 Standard + 1 Truck Cone
• Resolution: 0.01 oz, 1.4°
• Style: Auto & Light Truck

Ranger R980XR Tire Changer

• Shipping Weight: 716 lbs (324 kg)
• Maximum Tire Diameter: 50" (1,270 mm)
• Internal Rim Clamping: 10" – 30" (254 mm – 762 mm)
• External Rim Clamping: 9" – 28" (229 mm – 711 mm)
• Bead Breaker Width (Demounting): 1.5" – 13" (38 mm – 330 mm)
• Turntable Width (Mounting): 4" – 18" (102 mm – 457 mm)
• Design: Fixed Tower / Swing Arm
• Assist Type: Single-Tower Assist
• Speed: Standard
• Motor: 3 HP (220 VAC, 50–60 Hz)
• Air Requirement: 140–165 PSI (10–11 BAR)
• Drive System: Electric / Air
• Clamping: 4 Internal / External Clamps
• Table Clamping System: Dual Pneumatic Cylinders
• Bead Breaking System: Dual Pneumatic Blade
• Power Assist Towers: N/A
• Bead Seating: Turbo Blast System
• Shipping Dimensions: 43" × 51" × 44" (1,092 mm × 1,295 mm × 1,117 mm)
