Vollrath Heavy-Duty 60" Gas Charbroiler
Model CBGHD-60 • Countertop | Natural Gas / LP Convertible
Give your high-volume kitchen the firepower it deserves. The Vollrath CBGHD-60 Heavy-Duty Charbroiler delivers a massive 200,000 BTU of even, controllable heat across a full 5 feet of reversible cast-iron grates—perfect for everything from thick-cut steaks to delicate seafood. Built from rugged stainless steel with lifetime-guaranteed metal knobs, this ETL-listed workhorse is ready for years of nonstop service on the line.
Why you’ll love it
- 10 high-output burners (20,000 BTU each) spaced every 6" for precise zone control.
- Reversible cast-iron grates: narrow channels on one side to drain excess fat and reduce flare-ups, wider ribs on the flip side for fish and other delicate foods.
- Extra-deep, heat-retaining cast-iron radiants speed recovery and maintain consistent temperatures.
- Ships natural-gas-ready; LP conversion kit included for fast field change-over.
- Bull-nose front rail and heavy-duty 2 mm side/back splashes keep operators safe and the work area clean.
- Individual adjustable gas valves for each burner extend product life and simplify service.
- Four adjustable 4"–5½" legs allow quick leveling on any countertop.
- Smaller, easier-to-handle grease trays slide out the full depth of the unit.
- Metal control knobs are GUARANTEED FOR LIFE.
At-a-glance specs
| Overall dimensions (W × D × H) |
60.0" × 32.38" × 16.38" (152.4 cm × 82.2 cm × 41.6 cm) |
| Cooking surface |
60.0" × 24.0" (152.4 cm × 61.0 cm) |
| Burners / BTU |
10 burners | 200,000 BTU total (20,000 BTU each) |
| Gas connection |
¾" NPT, rear |
| Construction |
Stainless steel body, cast-iron grates & radiants |
| Certifications |
ETL, ETL Sanitation, cETLus |
| Included |
Radiant kit, NG to LP conversion kit, adjustable legs |
| Optional |
Lava Rock Kit #352578-1 (sold separately) |
| Warranty |
1-Year Standard Warranty | Lifetime metal knob warranty |
Installation & clearance
- For non-combustible surfaces only; maintain 6" rear clearance.
- No side clearance required from non-combustibles—perfect for tight lines.
- Install with legs to ensure proper airflow beneath the unit.
Gas hook-up required. Unit ships set for natural gas; use the supplied kit for propane conversion. All gas equipment must be installed by a qualified professional.
Specifications and design are subject to change without notice. Always refer to the latest Vollrath installation manual for detailed requirements.
